LEX FORENSIS Series Forensics Duplicator and Sanitizer

OVERVIEWS

The LEX FORENSIS is a first-of-its-kind EDSFF duplicator engineered for high-performance forensic imaging and data management. Delivering transfer speeds of up to 1500 MB/s, it enables rapid, reliable duplication for even the most demanding workflows.

Designed for maximum flexibility, the system supports bidirectional data operations, allowing users to seamlessly copy drive-to-drive, drive-to-image file, drive-to-network location, and drive-to-networked PC, and vice versa

This versatility makes the LEX FORENSIS equally suited for lab environments, field investigations, and enterprise data handling.

Built with modern digital forensics in mind, the LEX FORENSIS supports industry-standard image formats including DD, E01, and EX01, ensuring compatibility with leading forensic analysis tools and workflows.

For secure data sanitization, the system integrates a comprehensive suite of erasure methods aligned with National Institute of Standards and Technology (NIST) and U.S. Department of Defense (DoD) guidelines. Supported methods include Full Erase, Secure Erase, DoD Erase, Enhanced Secure Erase and more.

These capabilities ensure sensitive data is permanently removed in compliance with strict regulatory and security requirements.

In addition to its EDSFF capabilities, the LEX FORENSIS offers broad interface support, enabling operation across multiple storage technologies, including SATA, SAS, USB, M.2, U.2, andU.3.

This wide compatibility allows investigators and IT professionals to work with virtually any modern storage device without the need for additional adapters or systems.

Copy from Anywhere to Anywhere
True bidirectional duplication between drives, disk images, PCs, and network or cloud repositories.
NIST Compliant Sanitization Modes
Features several media sanitization methods including DoD erase, full erase (NIST clear), enhanced secure erase (NIST purge), and more.
Detailed Audit Logs
Comprehensive logs capturing hash values, serial numbers, model information, SMART data, and full job details.
Forensic Image Support
Supports industry-standard formats including DD, E01, and EX01.

DESCRIPTION

A blue graphic with the text Forensic Image Support and icons showing support for DD, E01, and EX01 file formats. A fingerprint shield icon appears next to the text, with a dark blue background.

Three touchscreen electronic devices showing support for various connections—SATA, SAS, USB, M.2, U.2, and U.3—against a blue background with the text “Broad Interface Support” above.

Diagram showing a forensic copy machine interface on a tablet, with arrows indicating bidirectional transfer between drives, forensic image files, PCs, and network locations on both sides.

Infographic showing four data erasure methods: DoD Erase, Full Erase (NIST Clear), Enhanced Secure Erase (NIST Purge), and more, each with a related icon and brief description on a dark blue background.

A digital graphic with the title DETAILED AUDIT LOGS above a sample Imaging Report document that lists machine info, case information, and work parameters on a dark blue background.

SPECIFICATION

General

Model	LEXF1000
Target	1

Specification

Maximum Transfer Speed	90 GB/min. Actual performance is dependent on device transfer speeds
Capacity	Supports the largest sized devices available on the market.
Operating Type	Stand-alone, PC-based for reliable dedicated performance
LCD Display	10.1″ touchscreen with 10-point PCAP touch; 1024×768 resolution

Features

Copy Anywhere to Anywhere	True bidirectional duplication between drives, disk images, PCs, and network or cloud repositories.
Hash Verification	Ensures data integrity with industry-standard hash verification during duplication.
NIST Compliant Sanitization Modes	Features several media sanitization methods including DoD erase, full erase (NIST clear), enhanced secure erase (NIST purge), and more.
Detailed Audit Logs	Comprehensive logs capturing hash values, serial numbers, model information, SMART data, and full job details.
Network Repository Support	Bidirectional duplication over SMB, NFS, SFTP, and iSCSI.
Forensic Image Support	Supports industry-standard formats including DD, E01, and EX01.

Compatibilities

Compatible Devices (NVMe)	● EDSFF (E1.S, E1.L, E3.S, E3.L) ● M.2 ● U.2/U.3
Compatible Devices (SATA/SAS)	● SATA/SAS
Compatible Devices (USB)	● USB Type A (2.0, 3.0. 3.1, 3.2)

Hardware specification

Network and Ports	●2x GbE RJ45 ●2x SATA/SAS ●2x USB 3.0 ●2x EDSFF ●2x Tool-less drive trays for M.2/U.2/U.3 Support ●1x HDMI
Peripheral USB ports	2x Back USB ports for keyboard and mouse operation
Power Requirements	●Power Adapter Input: 100-240VAC / 47-63Hz / 1.4A Max. ●Power Adapter Output: 24VDC / 5A
Operational Temperature	5°C ~ 45°C (41°F ~ 113°F)
Non-operational Temperature	-20°C ~85°C (-4°F ~ 185°F)
Humidity	● Operating: 20% ~ 80%, non-condensing ● Non-operating: 5% to 95%, non-condensing
Physical Dimensions (L×W×H)	LEXF1000– 290 mm x 180 mm x 72 mm (11.4 in. x 7.1 in. x 2.8 in.)
Product Weight	LEXF1000– 3.25 kg (7.2 lbs.)
Certifications	FCC, CE, RoHS, REACH

USER MANUAL

Title	LEX FORENSIS Series Forensics Duplicator and Sanitizer User Manual
Download	Coming Soon
