U-Reach M.2 NVMe/SATA/IDE Duplicator and Sanitizer 1-1

U-Reach M.2 NVMe/SATA Duplicator and Sanitizer 1-1 - U-Reach eStore

OVERVIEWS

Features
1) Speed transfers up to 24 GB/min (400 MB/sec).
2) Systems & files copy mode supports Windows(FAT16/32/64, NTFS), Linux(ext2/ext3/ext4), and Mac(HFS, HFS+, HFSX.)
3) Data Sanitization: Quick Erase, Full Erase, DoD Erase, and DoD Erase + Compare.
4) Open platform design supports NVMe (Gen 3 & Gen 4 & Gen 5) and SATA protocols.
5) Supports 1-1 cross-interface copy.
6) Supports M key and B+M key for all M.2 PCIe, M.2 SATA devices, SATA HDD/SSD devices, mSATA devices, and IDE devices.

Overview

The NVS200 is a 1:1 affordable and portable line of standalone multi-interface drive duplicators. These portable cloning unit provides advanced features not seen in your typical entry-level duplicator including support for PCIe M.2 NVMe SSD, M.2 SATA, 2.5”/3.5” SATA SSD/HDD, and IDE drives with adapter. The machine comes with an easy-to-use LCD interface with 4 button keypad, comprehensive wiping and cloning features.

The NVS200 provides the ability to create a bit-for-bit copy or use our “smart data and file systems only” mode to copy only data areas for extremely efficient cloning. These versatile duplicators make it easy to accomplish all your cloning and wiping tasks including drive testing, software and O/S upgrades, back-ups, content/application distribution and new PC rollouts.

TECH SPECS

General

Model	NVS200
Target	1

Specification

Maximum Transfer Speed	24.0GB/min. Actual performance is dependent on HDD transfer speeds
Capacity	Supports the largest sized devices available on the market.
Operating Type	Stand-alone, FPGA-based operation (Non PC-based)
Supported Languages	English, Japanese
LCD Display	Backlit Monochrome LCD Display
LEDs	3 LED Indicators per Port: Yellow (Power), Green (Pass), and Red (Fail)
Control Panel	4 Push Buttons(▲, ▼, OK, ESC)

Features

Copy Modes	Quick Copy (Systems & Files Copy), All Partition Copy, Whole Device Copy, Percentage Copy
Compare Function	Bit-by-bit data comparison
Sanitization Modes	Quick Erase, Full Erase, DoD Erase, Secure Erase, and more.

Compatibilities

Compatible Devices

NGFF (M.2): 2230, 2242, 2260, 2280, 22110, PCI-e SSD (full and low profiles)

SATA HDD/SSD

Supported Formats

Quick Copy: FAT16/32/64, Windows (NTFS), Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+,HFSX)
Whole Device Copy: All Formats, including proprietary formats

Supported O/S

All (Windows, Mac, Linux, and other stand-alone systems)

Hardware specification

Power Supply	Universal Power: 115VAC or 230VAC, 50/60Hz
Working Temperature	0°C ~ 60°C (32°F ~ 140°F)
Storage Temperature	-20°C ~85°C (-4°F ~ 185°F)
Working Humidity	20% ~ 95%, non-condensing
Storage Humidity	5% to 95%, non-condensing
Product Dimensions	11.5 in. x 9 in. x 3 in.
Weight (lbs)	3.6 lbs.
Certifications	FCC, CE, REACH, ICES-003
Compliance	NIST SP 800-88r1, ISO 27000

DISPLAY

USER MANUAL

Title	NVS200 PCIE SSD Duplicator v A.01
Download	Here
