U-Reach M.2/U.2/U.3 NVMe/SATA/SAS Duplicator and Sanitizer 1-1


SKU: NVS200USAS
Lead time: 2-4 Days
Please ensure that your browser cookies are enable for adding products to cart.

OVERVIEWS

Features
1) Speed transfers up to 24 GB/min (400 MB/sec).
2) Systems & files copy mode supports Windows(FAT16/32/64, NTFS), Linux(ext2/ext3/ext4), and Mac(HFS, HFS+, HFSX.)
3) Data Sanitization: Quick Erase, Full Erase, DoD Erase, and DoD Erase + Compare.
4) Open platform design supports NVMe (Gen 3 & Gen 4 & Gen 5), U.2, SATA, and SAS protocols.
5) Supports 1-1 cross-interface copy.
6) Supports M key and B+M key for all M.2 SATA/NVMe devices, U.2/U.3, SATA HDD/SSD devices, SAS HDD/SSD devices, mSATA devices

Overview

The NVS200USAS is a 1:1 affordable and portable line of standalone multi-interface drive duplicators. These portable cloning unit provides advanced features not seen in your typical entry-level duplicator including support for PCIe M.2/U.2/U.3 NVMe SSD, M.2 SATA, 2.5”/3.5” SATA SSD/HDD, and SAS drives. The machine comes with an easy-to-use LCD interface with 4 button keypad, comprehensive wiping and cloning features.

The NVS200USAS provides the ability to create a bit-for-bit copy or use our “smart data and file systems only” mode to copy only data areas for extremely efficient cloning. These versatile duplicators make it easy to accomplish all your cloning and wiping tasks including drive testing, software and O/S upgrades, back-ups, content/application distribution and new PC rollouts.



TECH SPECS

General

Model NVS200USAS
Target 1

Specification
Maximum Transfer Speed 24.0GB/min. *Actual performance is dependent on HDD transfer speeds*
Capacity Supports the largest sized devices available on the market.
Operating Type Stand-alone, FPGA-based operation (Non PC-based)
Supported Languages English, Japanese
LCD Display Backlit Monochrome LCD Display
LEDs  3 LED Indicators per Port: Yellow (Power), Green (Pass), and Red (Fail)
Control Panel 4 Push Buttons(▲, ▼, OK, ESC)

Features
Copy Modes Quick Copy (Systems & Files Copy), All Partition Copy,
Whole Device Copy, Percentage Copy
Compare Function Bit-by-bit data comparison
Sanitization Modes Quick Erase, Full Erase, DoD Erase, Secure Erase, and more.

Compatibilities
Compatible Devices

NGFF (M.2): 2230, 2242, 2260, 2280, 22110, PCI-e SSD (full and low profiles)

SATA HDD/SSD, SAS HDD/SSD, U.2, U.3

Supported Formats Quick Copy: FAT16/32/64, Windows (NTFS), Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+,HFSX)
Whole Device Copy: All Formats, including proprietary formats
Supported O/S All (Windows, Mac, Linux, and other stand-alone systems)

Hardware specification
Power Supply Universal Power: 115VAC or 230VAC, 50/60Hz
Working Temperature 0°C ~ 60°C (32°F ~ 140°F)
Storage Temperature -20°C ~85°C (-4°F ~ 185°F)
Working Humidity 20% ~ 95%, non-condensing
Storage Humidity 5% to 95%, non-condensing
Product Dimensions 11.5 in. x 9 in. x 3 in.
Weight (lbs) 3.6 lbs.
Certifications FCC, CE, REACH, ICES-003
Compliance NIST SP 800-88r1, ISO 27000

DISPLAY

USER MANUAL


Title

NVS200USAS Duplicator
 v A.01

Download Here
